Segway miniPRO Error Codes – App, Lights and Beeping
Error codes are displayed in the Ninebot app as well as displayed by lights (front or rear) and by sound. Please count blinks of the lights or beeps of the sound. The number corresponds with the error code.
| Code |
Description
|
Solutions |
| Error 5 | Power failed 12V | Replace the Control Board |
| Error 6 | Power failed 5 V | Replace the Control Board |
| Error 7 | Power failed 3.3 V | Replace the Control Board |
| Error 9 | CPU failed | Replace the Control Board |
| Errors 11-16 | Motor current sensor failed | Replace the Control Board or Motor |
| Error 17 | The BMS firmware is out of date | Update firmware |
| Error 18 | Rider Detect Button 1 failed | Check Rider Detect buttons |
| Error 19 | Rider Detect Button 2 failed | Check Rider Detect buttons |
| Error 21 | Linear hall sensor failed | Check all connections between Control Board, Steering Assembly and Center Console. If error remains replace Steering Sensor Board. |
| Error 22 | Weight sensor failed | Check weight sensor and connector. |
| Error 24 | Battery communication failed | Replace the battery. If the problem remains then replace the Control Board. You can also try to use after market battery without Ninebot Communication add-on. |
| Error 25 | BLE communication failed | Check connections between the Control Board and the Center console. If the error remains replace the center console electronics. |
| Error 26 | Drive voltage detect failed | Replace the Control Board |
| Error 27 | Cannot power off | Replace dashboard electronics or On/Off Button |
| Errors 28-29 | CPU initialization failed | Replace the Control Board |
| Errors 31-32 | Motor drive circuit failed | Check connections between motors and the Control Board. If the problem remains replace the Motor or the Control Board. |
| Error 33 | Abnormal Condition | This error indicated overload or overspeed. |
| Error 34 | Firmware update failed | Try to update the firmware again. |
| Error 35 | Gyroscope initialization failed | Replace the Control Board |
| Errors 36-41 | Motor sensor failed | Replace the Motor. |
| Error 51 | Battery temperature error | Cool down the battery. If the error remains replace the battery. |
| Error 52 | Battery voltage error | Replace the battery. |
